標準型自動Y-∆起動器
Type Standard Automatic Star-Delta Starters
|
標準型自動Y-∆起動器，外箱美觀、耐用，熱動過載繼電器有欠相保護裝置，起動時間由０∼３０秒視起動負荷之輕重，可隨意調整。
Type standard automatic Y-∆ starter is accommodated with door type external case, thermal relay with overload and phase failure protective equipment, starting time 0-30 sec. adjustable according to starting load.
請點擊以下型號觀看詳細內容 Click Type No. to view details. |
|
|
|
|
 |
 |
|
型號 Type |
最大適用馬達容量 Max Rating KW(HP) |
淨重
N/W |
外觀尺寸 (mm)
Outline Dimensions
|
||||||
| Enclosure | Open |
220V |
440V |
A |
B |
C |
AA |
BA |
|
| SBH-O-18 |
7.5 (10) |
11 (15) |
295 |
350 |
300 |
165 |
330 |
238 | |
| SBH-O-30 |
15 (20) |
22 (30) |
322 |
350 |
300 |
165 |
330 |
238 | |
| SBH-40 | SBH-O-40 | 22 (30) | 37 (50) | 295 | 450 | 400 | 185 | 380 | 260 |
| SBH-O-55 |
30 (40) |
45 (60) |
322 |
450 |
400 |
185 |
380 |
260 | |
| SBH-O-65 |
37 (50) |
55 (75) |
450 |
450 |
400 |
185 |
380 |
260 | |
|
A: |
Length |
B: |
Height |
C: |
Width |
AA: |
Hole for length |
BA: |
Hole for width |
